YNT-PR50-2050
Unity
| Availability: | |
|---|---|
| Quantity: | |
Our 25kg Bags Robotic Palletizer, a specialized Flour Bag Palletizing Robot under the Bag Palletizing Machine category, is a dedicated automation solution designed for the efficient and hygienic handling of flour bags at the end of your production packaging line—serving as a key End Of Line Palletizer. This robust system effortlessly lifts, transports, and stacks 25kg bags onto pallets with pinpoint accuracy. It is engineered to operate in powder-rich environments, featuring enhanced sealing and protection to ensure longevity and reliable performance. By automating this labor-intensive and physically demanding process, it significantly boosts packaging line efficiency, reduces product waste, and minimizes the risk of workplace injuries, providing a rapid return on investment.
Our 25kg Bags Robotic Palletizer, a specialized Flour Bag Palletizing Robot under the Bag Palletizing Machine category, is a dedicated automation solution designed for the efficient and hygienic handling of flour bags at the end of your production packaging line—serving as a key End Of Line Palletizer. This robust system effortlessly lifts, transports, and stacks 25kg bags onto pallets with pinpoint accuracy. It is engineered to operate in powder-rich environments, featuring enhanced sealing and protection to ensure longevity and reliable performance. By automating this labor-intensive and physically demanding process, it significantly boosts packaging line efficiency, reduces product waste, and minimizes the risk of workplace injuries, providing a rapid return on investment.
The robot in the Automatic Flour Palletizer System utilizes a high-precision servo control system and its motion trajectory has been optimized to ensure smooth and gentle movements when grabbing and placing flour bags. This effectively avoids impact and pulling on the bags, greatly reducing the risk of bag breakage and dust leakage, and ensuring damage-free transportation of products from the production line to the pallet.
Designed for the unique environment of flour production workshops, this Palletizing Automation Equipment utilizes key components with high dust protection levels and features a specialized dust-proof structure to effectively prevent dust from intruding into the core motion unit, extending the life of the equipment. All contact surfaces are constructed of food-grade stainless steel for easy cleaning and maintenance, fully complying with food industry hygiene and safety standards.
This Robotic Bag Palletizing unit can achieve palletizing speeds of up to 1200 bags/hour, easily matching the production cycle of high-speed packaging lines. Through a user-friendly touchscreen interface, operators can access hundreds of preset pallet configurations or quickly create new ones with a single click, enabling seamless switching between different products and pallet sizes to meet flexible production needs.
The modular design and automatic lubrication system of the equipment significantly reduce the complexity and frequency of routine maintenance. It can replace at least three to four manual workers, operating 24/7.
The robot in the Automatic Flour Palletizer System utilizes a high-precision servo control system and its motion trajectory has been optimized to ensure smooth and gentle movements when grabbing and placing flour bags. This effectively avoids impact and pulling on the bags, greatly reducing the risk of bag breakage and dust leakage, and ensuring damage-free transportation of products from the production line to the pallet.
Designed for the unique environment of flour production workshops, this Palletizing Automation Equipment utilizes key components with high dust protection levels and features a specialized dust-proof structure to effectively prevent dust from intruding into the core motion unit, extending the life of the equipment. All contact surfaces are constructed of food-grade stainless steel for easy cleaning and maintenance, fully complying with food industry hygiene and safety standards.
This Robotic Bag Palletizing unit can achieve palletizing speeds of up to 1200 bags/hour, easily matching the production cycle of high-speed packaging lines. Through a user-friendly touchscreen interface, operators can access hundreds of preset pallet configurations or quickly create new ones with a single click, enabling seamless switching between different products and pallet sizes to meet flexible production needs.
The modular design and automatic lubrication system of the equipment significantly reduce the complexity and frequency of routine maintenance. It can replace at least three to four manual workers, operating 24/7.
YNT-PR50-2050 | ||
Wrist rated load | 50kg | |
Max working radius (mm) | 2050 | |
Degrees of freedom | 6 axis | |
Rated load speed | J1 | 160 °/s |
J2 | 120°/s | |
J3 | 120°/s | |
J4 | 225°/s | |
J5 | 225°/s | |
J6 | 225°/s | |
Joint motion range (°) | J1 | ±185° |
J2 | -85°~+135° | |
J3 | -200°~+75° | |
J4 | ±360° | |
J5 | ±120° | |
J6 | ±360° | |
Protection level | IP54 | |
Repeat positioning accuracy (mm) | +0.06mm | |
working temperature | 0-45° | |
YNT-PR50-2050 | ||
Wrist rated load | 50kg | |
Max working radius (mm) | 2050 | |
Degrees of freedom | 6 axis | |
Rated load speed | J1 | 160 °/s |
J2 | 120°/s | |
J3 | 120°/s | |
J4 | 225°/s | |
J5 | 225°/s | |
J6 | 225°/s | |
Joint motion range (°) | J1 | ±185° |
J2 | -85°~+135° | |
J3 | -200°~+75° | |
J4 | ±360° | |
J5 | ±120° | |
J6 | ±360° | |
Protection level | IP54 | |
Repeat positioning accuracy (mm) | +0.06mm | |
working temperature | 0-45° | |
Perfectly integrated at the end of the flour production line, this unit automatically receives 25kg flour bags from the packaging machine and stacks them into stable, neat stacks for direct storage or transportation. It is a key piece of equipment for achieving "unmanned" operations.
It is used for palletizing bagged products of powdered and granular materials such as rice, grains, and various animal feeds. Its dust resistance makes it excellent in such environments.
It is suitable for palletizing bagged products such as starch, powdered sugar, yeast, and other food additives. Its hygienic design meets strict food safety regulations.
Perfectly integrated at the end of the flour production line, this unit automatically receives 25kg flour bags from the packaging machine and stacks them into stable, neat stacks for direct storage or transportation. It is a key piece of equipment for achieving "unmanned" operations.
It is used for palletizing bagged products of powdered and granular materials such as rice, grains, and various animal feeds. Its dust resistance makes it excellent in such environments.
It is suitable for palletizing bagged products such as starch, powdered sugar, yeast, and other food additives. Its hygienic design meets strict food safety regulations.
Operating this palletizing robot is incredibly simple. Using an intuitive touchscreen interface, operators can easily select pre-set pallet configurations, adjust parameters like the number of layers and columns, and initiate fully automatic operation with a single click. Daily operation requires only a few steps: "Select Program," "Start," and "Stop." A manual mode is available for commissioning and fine-tuning positions. We provide comprehensive on-site operator training, and a comprehensive Chinese-language operating and maintenance manual is also included.
Operating this palletizing robot is incredibly simple. Using an intuitive touchscreen interface, operators can easily select pre-set pallet configurations, adjust parameters like the number of layers and columns, and initiate fully automatic operation with a single click. Daily operation requires only a few steps: "Select Program," "Start," and "Stop." A manual mode is available for commissioning and fine-tuning positions. We provide comprehensive on-site operator training, and a comprehensive Chinese-language operating and maintenance manual is also included.
